SPIN Coater
Spin Coater
Biostag technologies have designed and fabricate very compact and reliable Spin Coater and highly affordable, allowing everyone to implement spin coating in their research. It offers high-quality coating without the issues of substrate warping. As it does not require a vacuum pump and its compact size and reduced need for servicing enables you to optimise space in the glove box or on the bench without compromising on functionality.
Main Features
- Compact, safe, space saving design, reliable, cost effective Spin Coater.
- DC Brushless Motor
- Digital Display for Speed and Time,
- Vacuum and Vacuum less Chuck
- User Multiple programmable
- Automated standby mode
- Microprocessor based controlling
- Low maintenance
- Two Year Warranty
- Multiple chucks for substrate holding
Technical Specification
| Specification/Model | BST-SC06T | BST-SC08T | BST-SC12AT |
|---|---|---|---|
| Maximum RPM | 6000 | 8000 | 12000 |
| Holding Method | With Vacuum & W/V | Both | Both |
| User Programmable | Only 1 input | 10 Programme | 10 Programme |
| Display | LED Digital Display | Large back lit LCD | Large back lit LCD |
| Motor Type | BLDC Brushless Motor | BLDC Brushless Motor | BLDC Brushless Motor |
| Timer | 1-99 Min & Continuous | 1-999 & Continuous | Programmable |
| Rotational Platform | 70mm | 70mm | 70mm |
| Chuck | All type of slides | All type | All type |
| Chuck Dimensions | 12, 24, 30, 40, 70 mm | All type | All type |
| Dimensions | 250 x 260 x 250 mm | 250 x 265 x 200 mm | 250 x 265 x 200 mm |
